Yar Yi Light linear actuator YA10B

Share

Issue Time: 2021/06/12

Summary

HTW10B industrial linear actuator is a very powerful actuator designed for various applications such as agricultural machinery, construction machinery, and industrial machinery.

YA10B industrial linear actuator is a very powerful actuator designed for various applications such as agricultural machinery, construction machinery, and industrial machinery. Configure the standard YA10B linear actuator. Due to its large capacity, well-designed, and IP65-rated protection, Yar Yi actuators are ideal for agricultural, construction, and industrial machinery plants. The biggest advantage; can adjust the stroke, installation length and product durability. All-product all-metal materials do not contain any plastic parts.

The following are general features of YA10B:

1. Voltage of motor: 12V DC, 24V DC, 36V DC, 48V DC

2. Maximum load: 7,000N

3. Maximum speed at full load: 23mm/s ( load 2,000N)

4. The slowest speed at full load: 5.5mm / s (Load 7,500N)

5. Stroke: 50~800mm

6. Minimum dimensions: Stroke + 250 mm(S＜400mm)

: Stroke + 300 mm(S＞400mm)

7. Color: black

The following figure is the packaging diagram of the product when it is shipped, for reference and view by other customers who are interested in the product and other customers who are interested in purchasing the product.
