Yar Yi's YA350 series electro-hydraulic linear actuators are designed for heavy duty applications.
Yar Yi Hydraulic Cylinder Linear Actuator YA350
Yar Yi's YA350 series electro-hydraulic linear actuators are designed for heavy duty applications that are developed in harsh environments where high lifting capacity and retention are required. Products are widely used in sanitation trucks, electric three-wheeled agricultural vehicles, yacht outboard machine, lift platform, ship car mechanics etc.
The following are general features of YA350:
1. Voltage of motor: 12V DC, 24V DC
2. Maximum load: 50,000N
3. Stroke: 100~600mm
4. Minimum dimensions: Stroke + 200mm(it will vary according to different load)
5. Color: black
6. IP rating: IPX6
7. Operational temperature range: -20°C~+60°C
8. Duty cycle: 4min on, 16min off
The following figure is the shipping diagram of the product, for reference and viewing by customers who are interested in the product and customers who are interested in buying the product.
